FreeScan Combo Series

Hybrid Light Source and Multifuncional Handheld 3D Scanner

Scanners from the powerful FreeScan Combo Series pack dual light sources in an ultra compact shell, measuring just 193 x 63 x 53mm. They´re equipped with both blue laser and infrared VCSEL technology and weigh in at only 620g.

Design

An innovative combination of blue laser and infrared light sources meets the needs of diverse industrial 3D scanning scenarios.

Scanning Modes

Multiple-line mode with 26 or 50 laser lines for overall scans.

Fine scanning mode with 7 parallel laser lines to acquire intricate details.

Deep hole scanning mode with 1 single laser line.

Infrared light mode for quick scans without markers.

Accuracy



The FreeScan Combo Series laser scanning modes can achieve industrial-grade accuracy up to 0.02mm, ideal for metrology applications.

FreeScan Combo Series and Exmodel Pro Bundle

SHINING 3D, a global pioneer in the 3D digitization and scanning industry, is thrilled to announce the launch of EXModel. This software facilitates a seamless transition from 3D scanning to manufacturing, acting as a solid bridge for CAD modeling. It features a simple workflow and intuitive user interface, making reverse engineering a breeze.

Bridging Your Scan Data and CAD Models

EXModel is equipped with a comprehensive set of tools that can easily transform 3D scanning meshes into professional-grade CAD solid models. The software aims to extract all necessary elements from meshes for immediate use in CAD software, bridging the gap between 3D scanning and design.

EXModel performs excellently in streamlining workflows. It can seamlessly convert 3D scans into CAD, providing an intuitive and comprehensive reverse engineering solution. This means that meshes can be transformed into professional-grade CAD solid models in a few simple steps.

In addition, EXModel provides a variety of export options. Users can export in standard IGES or STEP file formats for seamless integration with other CAD/CAM software packages. These exports can also be used for 3D printing or CNC machining, significantly lowering the entry barrier and enhancing the overall value of the scanner and industry-standard software.

To celebrate the release of EXModel, SHINING 3D is offering a 30-day free trial for new users, providing a great opportunity to personally experience the functionality and efficiency of the software. In addition, EXModel Pro also offers a 15-day free trial, allowing users to experience the extra features and advantages of the Pro version.

FreeScan Trio

First Marker-Free Laser 3D Scanner, 98 Laser Lines, Zero Markers.

The FreeScan Trio’s thorough 98-laser-line mode eliminates the need for markers, efficiently capturing all your workpieces. Paired with an ultra-fast scan speed of up to 3,010,000 points/s, you’ll truly feel the acceleration in your workflow

Scan Modes

98 laser lines: Marker-free, ultra-fast scan speed of up to 3,010,000 points/s
26 laser lines: 650x580mm FOV for fast 3D scanning
7 laser lines: Industrial-grade, 5MP cameras to capture exceptional detail
1 laser line: Optimized camera angle for pockets and holes

Accuracy

Unrelenting Accuracy and Precision

For quality control, inspection, and reverse engineering, its 0.02 mm accuracy (with markers) and high-precision performance deliver results you can count on, time and time again.

 Data generated with the 26 laser line mode.
Compared to the CAD file.

Based on VDl/VDE 2634, sphere-spacing error is assessed with traceable length artefacts and markers by measuring these at different locations and orientations within the working volume, in the accuracy lab certified with ISO/IEC 17025:2017 with environment conditions: temperature 20 ± 0.5℃; humidity 40 ~ 60% RH.

OptimScan 5M Plus

High-Precision 3D Inspection System

OptimScan-5M Plus is High-Precision 3D Inspection scanner with narrow-band blue light source and upgraded high-resolution industrial lens, it provides better detail performance in scanning and smoother data quality.
Three sets of high-resolution industrial lenses are used according to different size object, making it more flexible and adaptable. It is widely applied in reverse engineering, quality inspection and quality control.

High Resolution

Three 5 mega pixel high resolution cameras and 1080P projection were used to obtain high precision features.

Scan Range

Multiple Scan Range

Different scanning range is realized by switching off different lenses and recalibration to ensure a finer scanning performance. Different lenses have the same working distance without manual adjustment.



High Accuracy

Single shot accuracy can reach up to 0.005mm, scanner provides the function of environmental vibration detection and effectively ensure high quality data and precision.
